제품 설명
PET 4&Blot Vertical electrophoresis transfer cell（1.5mm）
제품 번호
80243ES
제품 설명
PET 4&Blot Vertical electrophoresis transfer cell product includes both an electrophoresis device capable of running protein gels and a transfer kit component of a mini vertical transfer tank. It enables the transfer of protein gels using the transfer kit after electrophoresis is completed.
High-throughput: Enables 4-gel electrophoresis + 2-gel transfer in parallel, optimizing workflow.
Uniform Transfer: Vertical design ensures even electric field distribution for consistent results.
Broad Compatibility: Fits standard gel sizes (e.g., Mini-PROTEAN) and various membrane types.
User-Friendly: Modular assembly for easy disassembly and cleaning.
Durable & Safe: Corrosion-resistant electrodes and transparent casing for monitoring.
Protein Research: Western blot (WB) for protein detection and analysis.
Nucleic Acid Transfer: Southern/Northern blotting for DNA/RNA studies.
Molecular Biology: Compatible with SDS-PAGE & Native-PAGE gels for protein separation and transfer.
Biomedical & Diagnostic Studies: Used in disease research, biomarker detection, and antibody validation.
Academic & Industrial Labs: Suitable for high-throughput labs needing dual-gel transfer efficiency.
Product Code | Product Name | Qty | Unit | Description |
80805ES05 | Comb | 5 | pcs | 1.5 mm, 10 teeth |
80806ES05 | Comb | 5 | pcs | 1.5 mm, 15 teeth |
80809ES05 | Spacer Glass Plate | 5 | pcs | 1.5 mm, 100*83 mm |
80810ES05 | Short Glass Plate | 10 | pcs | 100*73 mm |
80811ES05 | Gel Casting Base | 4 | pcs | For gel casting |
80812ES05 | Gel Pouring Frame | 4 | pcs | For gel pouring |
80815ES20 | Gel Pouring Frame Hinge | 8 | pcs | Installed on the gel pouring frame |
80814ES05 | Gel Casting Gasket | 5 | pcs | For sealing glass, placed under the gel casting base |
80816ES05 | U-Shaped Sealing Strip | 4 | pcs | For sealing the gel chamber, installed on both sides of the electrophoresis core |
80817ES05 | U-Shaped Sealing Strip (Precast Gel) | 4 | pcs | For sealing the gel chamber, specifically for precast gels |
80818ES05 | Electrophoresis Core Side Clamp | 4 | pcs | Installed on both sides of the electrophoresis core for clamping |
80819ES05 | Electrode Head Electrophoresis Core | 1 | set | Direct power supply |
80820ES05 | Mushroom Head Electrophoresis Core | 1 | set | Indirect power supply |
80821ES05 | Buffer Barrier | 1 | pcs | Used when running 1 gel |
80822ES05 | Gel Spatula | 5 | pcs | For prying open glass plates |
80823ES05 | Sample Loading Stand | 1 | pcs | Facilitates sample loading |
80824ES05 | Upper Cover (with cable) | 1 | set | Upper cover with power cable |
80825ES05 | Lower Cover | 1 | set | Tank base |
80827ES05 | Glass Plate Holder | 1 | pcs | Holds 14 glass plates |
80828ES05 | Centrifuge Tube Rack | 1 | pcs | Holds 91 centrifuge tubes of different sizes |
80830ES05 | Transfer Frame | 1 | pcs | With platinum electrodes, for placing transfer clamps |
80831ES05 | Transfer Clamp | 2 | pcs | 100*75 mm, two connected perforated plates |
80832ES05 | Large Hole Sponge | 5 | pcs | For wrapping gels and nitrocellulose membranes |
80833ES05 | Cooling Module | 2 | pcs | For cooling, can be alternated |
| Quality Certificate | 1 | pcs | Inspection passed |
| Instruction Manual | 1 | copy | Product usage instructions |
| Packing List | 1 | copy | List of components |
Components No. | Name |
|
80212ES | MiniPro™ PET4 Vertical Electrophoresis Tank（1.5mm） | 1 Unit |
80834ES | Transfer kit | 1 Unit |
Transport at ambient temperature, store at room temperature.
