제품 설명
PET 2&Blot Vertical electrophoresis transfer cell（1.0mm）
제품 번호
80240ES
제품 설명
PET 2&Blot Vertical electrophoresis transfer cell product includes both an electrophoresis device capable of running protein gels and a transfer kit component of a mini vertical transfer tank. It enables the transfer of protein gels using the transfer kit after electrophoresis is completed.
Capacity: Holds two transfer cassettes simultaneously for protein/nucleic acid transfer.
Cooling system: Includes built-in cooling modules (pre-frozen) to absorb heat during fast transfers, eliminating the need for external cooling devices.
Gel compatibility: Works with SDS-PAGE & Native-PAG gels .
User-friendly design:Easy-lock mechanism for secure gel assembly.
Transfer modes: Supports high-current (fast transfer) or low-current (overnight) protocols.
Safety: Automatic power cutoff when the lid is opened.
Warranty: 2-year quality guarantee (excludes misuse/modifications).
Capacity: Holds two transfer cassettes simultaneously for protein/nucleic acid transfer.
Cooling system: Includes built-in cooling modules (pre-frozen) to absorb heat during fast transfers, eliminating the need for external cooling devices.
Gel compatibility: Works with SDS-PAGE & Native-PAG gels .
User-friendly design:Easy-lock mechanism for secure gel assembly.
Transfer modes: Supports high-current (fast transfer) or low-current (overnight) protocols.
Safety: Automatic power cutoff when the lid is opened.
Warranty: 2-year quality guarantee (excludes misuse/modifications).
Part No. | Product Name | Qty | Unit | Description |
80801ES05 | Comb | 3 | pcs | 1.0 mm, 10 teeth |
80802ES05 | Comb | 3 | pcs | 1.0 mm, 15 teeth |
80808ES05 | Spacer Glass Plate | 3 | pcs | 1.0 mm, 100×83 mm |
80810ES05 | Short Glass Plate | 5 | pcs | 100×73 mm |
80811ES05 | Gel Casting Base | 2 | pcs | For gel casting |
80812ES05 | Gel Casting Frame | 2 | pcs | For gel pouring |
80815ES20 | Gel Casting Frame Hinge | 4 | pcs | Mounted on gel casting frame |
80814ES05 | Gel Casting Gasket | 3 | pcs | For glass sealing, placed under casting base |
80816ES05 | U-Shaped Seal Strip | 2 | pcs | For chamber sealing, mounted on both sides of core |
80817ES05 | U-Shaped Seal Strip (Precast) | 2 | pcs | For precast gel chamber sealing |
80818ES05 | Electrophoresis Core Clip | 2 | pcs | Mounted on core sides for fastening |
80819ES05 | Electrode Head Core | 1 | set | Direct power connection |
80821ES05 | Buffer Barrier | 1 | pcs | For running 1 gel |
80822ES05 | Gel Spatula | 3 | pcs | For prying open glass plates |
80823ES05 | Sample Loading Rack | 1 | pcs | For convenient sample loading |
80824ES05 | Upper Cover (with Cable) | 1 | set | Top cover with power cable |
80825ES05 | Lower Cover | 1 | set | Base tank |
80827ES05 | Glass Plate Holder | 1 | pcs | Holds 14 glass plates |
80828ES05 | Centrifuge Tube Rack | 1 | pcs | Holds 91 tubes of different sizes |
80830ES05 | Transfer Frame | 1 | pcs | With platinum electrodes for transfer clamps |
80831ES05 | Transfer Clamp | 2 | pcs | 100×75 mm, two connected perforated plates |
80832ES05 | Large Pore Sponge | 5 | pcs | For wrapping gels and nitrocellulose membranes |
80833ES05 | Cooling Module | 2 | pcs | For cooling, interchangeable |
| Quality Certificate | 1 | pcs | Quality inspection passed |
| User Manual | 1 | copy | Product instructions |
| Packing List | 1 | copy | List of included components |
Components No. | Name |
|
80210ES | MiniPro™ PET 2 Vertical Electrophoresis Tank（1.0mm） | 1 Unit |
80834ES | Transfer kit | 1 Unit |
Transport at ambient temperature, store at room temperature.
